G-CUBE 96kWh High Voltage Battery • GenixGreen Pakistan

GENIXGREEN G-CUBE 96kWh High Voltage LiFePO4 Battery Outdoor Energy Storage System

1. Plug and play Play and plug in
2. The system has high energy density, saving transportation costs and installation space
3. Reduce the operational risks of the installer in the installation process and improve product stability
4. The whole system is intelligently designed, and the full-time BMS balance keeps the SOC more accurate, improves the consistency of the battery cells and ensures a working life of more than 10 years for the system
5. Integrate air conditioning system and fire protection system. Improve product stability and safety
6. Support multi-machine parallel system (AC convergence), such as when connected to the power grid, the parallel connection is not limited by quantity. Off-grid parallel operation <4 sets (need to distinguish the customer’s off-grid load type and load power)

SKU: G-CUBE 96

Category: High Voltage LiFePO4 Battery, Industrial Commercial Energy Storage

Brands: GENIXGREEN

Get a Product Quote

Tags: 96kWh, Floor standing, G-CUBE 96, G-CUBE Series, High Voltage LiFePO4 Battery, HV, IP55, Outdoor

Description

Model		G-CUBE 96 kWh
Bettery type		LiFePO4
Module nominal energy(kwh)		16
Module minimun energy (kwh)		15.5
Module nominal voltage(V)		76.8
Rated capacity(Ah)		206
No. of System module seriesconnections(optional)		4	5	6
Rated Voltage of the system(V)		307.2	384	460.8
System working voltage(V)		268.8-345.6	336~432	403.2~518.4
System nominal energy(KWh)		64	80	96
Minimum discharge energy ofthe system (KWh)		60.74	75.93	91.12
Charge /Discharge current(A)	Rated Current	120
	Max. Current	130
	Overload Current	150(10sec,25°C)
Status indicator light		Blue:Battery system starts status;Green:Battery system operation status; Red: Battery system fault status
Communication Protoco		CAN2.0
Working temperature range(℃)		-10~50
Working humidity range		≤95%(No Condensation)
Working Alitude		≤2000m
System Cooling Method		Fan cooling
Waterproof Grade		IP55
Installation Place		Outdoor
Net Weight(kg)		≈1100	≈1225	≈1350
Dimension(mm)		107911662157
Recommended Discharge Depth		0~35
Storage Temperature(°C)		90%
System Composition		BMS management system, fire protection system, air-cooled unit, cabinet, PCS system
Cycle Life		25+2°C/0.2C/80%≥6000
Certification		Cel:UL1973/EC62619/CE/ROHS/MSDS/UN38.3
PS: 1. The testing conditions for the minimum discharge energy of the system are: charging and discharging at 0.2C at 25 °C. (The minimumenergy of the system may vary depending on the system configuration parameters)
